CNC machining for the metal part in your drawing.
Housings, brackets, plates and ported blocks require more than a generic machine quote. Send the drawing and tell us which faces, bores and fits make the part work; we will review the route before pricing.
Drawing-defined CNC metal components, from a prototype to repeat production.
01Drawing-first manufacturing review
02CNC milling, turning & finishing
03Prototype → repeat batch
WHO WE ARE
Factory-direct support for drawing-led CNC parts.
KEC Tour supports international OEM and engineering buyers sourcing custom metal components from drawings and approved samples. CNC machining can be coordinated with finishing, inspection and later repeat orders.
See the company and quality workflow →WHY BUYERS WORK WITH US
The useful questions come before the first cut.
Functional datums
Identify the faces and holes the assembly actually locates from.
Quote scope
Agree finish, inspection, sample and packing requirements with the cut part.
IS THIS THE RIGHT RFQ?
Check the scope before you send.
This page is for an individual machined metal component with enough application context to review feasibility.
Good fit for KEC Tour
- Custom CNC metal parts from a drawing or sample
- Prototypes and planned repeat batches
- Defined material and functional features to review
Outside this page’s scope
- Stock machine parts or retail hardware
- Complete equipment or unverified functional guarantees
OUR SERVICES
Choose the route by geometry and function.
A milled housing, flat bracket and ported body have different setups, datum strategies and inspection needs.
CNC milling
Pockets, faces, hole patterns and ported blocks from released 2D/3D data.
CNC turning
Round features, bores and concentric seats where the geometry calls for it.
Secondary operations
Drilling, tapping, deburring and finishing reviewed against the part.
Inspection planning
Critical dimensions, gauges and first-article evidence agreed before order.
PART-TO-PROCESS MATCH
Inspect the machined shapes closest to yours.
Rotate representative housings, brackets, flanges and ported bodies. Your released drawing determines the actual part.
Select a part to load its interactive model.
INTERACTIVE 3D · REPRESENTATIVE GEOMETRY
Rotate the part. Inspect the features.
Use the models to discuss machining access and mating features. They are illustrative geometry, not validated customer designs.
Model geometry illustrates part families only. Threads, tolerances and performance come from your approved drawing.ENGINEERING SPECIFICATION
Six questions behind a useful CNC quote.
Separate the critical geometry from the dimensions that can follow normal machining practice.
| Decision | What to define | Why it matters |
|---|---|---|
| Drawing revision | Latest 2D PDF and STEP/STP model if available | Prevents a process plan being based on an obsolete shape. |
| Material | Alloy, grade, condition and substitution rule | Changes stock choice, tooling and finishing. |
| Datum scheme | Faces, axes and hole patterns used at assembly | Controls setup and inspection alignment. |
| Critical features | Fits, bores, flatness, position or surface finish | Shows where tolerance and measurement effort belong. |
| Quantity | Prototype count, batch size and forecast | Affects fixturing and cost per part. |
| After machining | Finish, marking, inspection records and packing | Defines the delivered component rather than the raw machined shape. |
Use this as a discussion guide. Final requirements come from the approved drawing, application standard and purchase documents.
RFQ FILE PACK
Give the machining team a usable starting pack.
A complete pack reduces clarification rounds. You can still start with a sample or partial drawing.
Part files
2D drawing and STEP/STP model; mark the current revision.
Application
Mating part, assembly location and function-critical surfaces.
Program volume
Prototype and likely repeat quantities with a target date.
Acceptance
Material record, critical measurements, finish and packing needs.
No finished drawing yet? Send the sample photo and the dimensions you know; identify what remains undecided.
Start an RFQ ↗INSIDE THE WORKSHOP
See the workshop behind the machining route.
The original workshop footage shows machining and part handling. The final machine route, finish and inspection plan depend on your drawing and agreed quotation.
ILLUSTRATIVE ASSEMBLY STUDY
How component interfaces become an assembly.
The illustrative housing/insert/cover animation highlights why bores, seating faces and fastener locations must be defined together. It is not a performance test.
APPLICATION & SOURCING DECISIONS
Choose the part family before choosing the price.
Three common jobs reveal different manufacturing and inspection priorities.
Machined housing
Review bore relationships, mounting faces, port access and any sealing feature.
Structural bracket
Define the base datum, hole pattern, flatness and finishing exposure.
Ported block
Clarify intersecting bores, deburring, cleanliness and the inspection method.
SAMPLE TO BATCH
Approve the sample before the repeat batch.
Carry the approved revision and critical features from the first article into the production order.
- 01
Review the drawing
Identify the material, datums and functional geometry.
- 02
Plan the route
Assess setups, machining access, secondary work and finish.
- 03
Approve a sample
Agree fit and critical measurement evidence on the first article.
- 04
Release the batch
Use the approved revision and agreed checks for repeat supply.
INSPECTION & DOCUMENTATION
Define what must be measured and recorded.
Tolerance, certificate and inspection scope are project-specific. Specify the acceptance method in the RFQ and confirm it in the quotation.
- Critical-dimension report by agreed scope
- Material and finish records when specified
- First-article and batch checks tied to the approved revision
FACTORY DOCUMENTATION
Review the evidence behind the process.
Certificates are issued to Dongguan Xuxiang Precision Metal Products Co., Ltd. KEC Tour is the website brand, not the named certificate holder. Ask us to confirm the manufacturing entity, certified site, scope and applicability to your order.
Discuss inspection and documentation →
ISO 14001:2015Environmental management · View document ↗
QC 080000:2017Hazardous substances process management · View document ↗YOUR CONFIDENTIAL DRAWINGS
Need an NDA before sharing files?
Tell us before you upload controlled drawings. We can discuss the confidentiality agreement and the permitted review scope first. Share only files your organization authorizes you to disclose.
Request an NDA discussion ↗Read the Privacy Policy →Uploading a file does not itself create an NDA.
BEFORE YOU SEND
Useful answers for your RFQ.
Can I start with only a photo?
A photo can start a feasibility discussion. A dimensioned drawing or approved sample is needed to define a reliable quote.
Do you support prototypes?
Share the prototype quantity and expected repeat volume so the initial route can be compared with the batch need.
Which tolerances are possible?
Tolerances are reviewed feature by feature against material, geometry, process and inspection method; no universal value applies.
Can I request an NDA?
Contact KEC Tour before uploading controlled files to discuss the agreement and permitted review scope.
Ready to review your CNC part?
Send a drawing or sample image with material, quantity and the features that matter at assembly.
